Gas Regulator, Nitrogen, Single Stage, 0.965"-14 Inlet, 1/4"-37 Outlet, 10 to 400 psi
Description
Gas Regulator, Maximum Gauge Outlet Pressure 4,000 psig, Number of Stages Single Stage, Compatible Gas Type Nitrogen, Control Type T-Handle, Inlet Connection Type NGO, Inlet Connection Gender Male, Inlet Connection Size 0.965 In.-14, Outlet Pressure (Maximum) 400 psi, Outlet Connection Gender Female, Outlet Connection Size 1/4 In.-37, Outlet Connection Type 37 Degrees Flared Tube, Body Material Brass, Diaphragm Material Neoprene, CGA Number CGA 580, Application Purging, Duty Rating Light Duty
Dimensions
| Outlet Connection Size | 1/4"-37 |
| Gauge Diameter | 2 in |
| Inlet Connection Size | 0.965"-14 |
| Overall Length | 6-1/4"" |
| Overall Depth | 4.25 in |
| Overall Height | 5.1 in |
| Overall Width | 6.38 in |
| Dedupe with CGA Number and Inlet Connection Size | CGA 580 |
Gas Regulator, Nitrogen, Single Stage, 0.965"-14 Inlet, 1/4"-37 Outlet, 10 to 400 psi
$200.99
